AUTOMATIC EDGE BANDING MACHINE Functions of gluing,end cutting, rough trimming, fine trimming, scraping and buffing
Automatic Edge Banding Machine
The glue mechanism adopts a special structure to gelatinize the plates and costing materials uniformly, ensure a more solid conglutination.
End trimming mechanism through a precise guide track movement; adopt automatic tracking and high frequency motor fast cutting structure to ensure the cutting surface smoothly.
Rough/fine trimming mechanism is used for repairing the excess edge materials, adopt automatic tracking and high frequency motor fast cutting structure to ensure the trimming plates smoothly.
Scraping unit is for a perfect finishing of the applied edge.
The buffing device adopts the board processed by cotton polishing wheel, by end polishing to make a more smooth surface.
TEM/MODEL | MFB486 |
Panel thickness | 10-60mm |
Min. panel length | 150mm |
Min. panel width | 60mm |
Edge tape thickness | 0.4-3mm |
Feeding speed | 13-20m/min |
Total power | 10.52kw |
Working air pressure | 0.6Mpa |
Overall dimensions | 4460*805*1500 |
Net weight | 1442kgs |
